System
| POE | No |
| ONVIF | Yes |
Video/Audio
| Video Input | 16CH Over Network |
| Standard Video Output | CVBS (Spot), VGA |
| Advanced Output | HDMI |
| Audio Input | Depends on Camera Stream |
| Audio Output | 1CH |
| Two Way Audio | Yes |
Recording
| Real-Time Recording | 16CH 720P Real-Time |
| 1080P | 120FPS (NTSC)/100FPS (PAL) |
| 720P | 240FPS (NTSC)/200FPS (PAL) |
| 960H | No |
| D1 | 240FPS (NTSC)/200FPS (PAL) |
| CIF | No |
| Recording Modes | Schedule, Manual, Motion, Sensor |
| Playback Channel | 16-ch |
| Search Mode | Time, Event, File Management |
Backup
| USB | 1 USB 2.0 Port |
| DVD Burner | No |
| Backup Format | AVI/DAT |
Remote Application
| Dual Stream | Master Stream 1-25/30FPS@720P, Sub-Stream 1-25/30FPS@CIF |
| Browser | IE, Chrome, Safari, Firefox (Mac OS, Windows XP/Vista/7/8) |
| Master Stream in Network | Yes |
| CMS | Yes |
| 3G | ProvisionCAM for iOS/Android |
| User Access | 20 Users Online with Professional Autorithy Management |
Alarm
| Input | 16 |
| Output | 1 |
Storage
| HDD | 1 SATA (3TB) |
| E-SATA | No |
PTZ
| Connection | Yes via Network |
| Supported Controls | Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus |
| RS-485 | Yes |
Network
| Ethernet | 100 Mbps (RJ-45) |
| Protocol | TCP/IP, DHCP, DDNS, NTP, SMTP |
Others
| Dimention | W300xD260xH55mm |
| IR Controller | Yes |
| Power Supply | 12V/2A |
| Operation Temperature | 0°C ~50°C |
